XWF 30.20 Annovi Reverberi Solid Shaft Pump – 30 L/min @ 200 Bar, 24mm Shaft, 1000 RPM – Part No: XWF30.20
SKU : XWF30.20
Regular price £855.00
Ask about XWF 30.20 Annovi Reverberi Solid Shaft Pump – 30 L/min @ 200 Bar, 24mm Shaft, 1000 RPM – Part No: XWF30.20
Product Details
The XWF 30.20 Annovi Reverberi solid shaft pump is engineered for high-volume, low-speed applications — ideal for use with tractor PTO systems and other 1000 RPM drives. Fitted with a 24mm solid shaft, it’s perfectly suited for coupling with PTO gearboxes or slow-speed electric or hydraulic motors.
Delivering an output of 30 litres per minute at 200 Bar (3000 PSI), this pump requires approximately 15 HP to run at full pressure. It uses a 3-piston alternating volumetric design, driven by a crank-connecting rod mechanism, to ensure consistent high-flow performance under demanding conditions.
The die-cast aluminium alloy pump body and cover provide excellent strength-to-weight performance, while a rear oil sight glass and drain outlet simplify maintenance. Side covers may be supplied with or without oil sight glass depending on the build.
Designed for heavy-duty industrial cleaning systems, the XWF30.20 is a popular option in agriculture, construction, and plant maintenance setups.
Specifications
PDF Downloads
Downloads
