RC 13.17 Annovi Reverberi Solid Shaft Pump – 13 L/min @ 170 Bar, 24mm Shaft, 1450 RPM – Part No: RC13.17
SKU : RC1317
Regular price £289.00
Ask about RC 13.17 Annovi Reverberi Solid Shaft Pump – 13 L/min @ 170 Bar, 24mm Shaft, 1450 RPM – Part No: RC13.17
Product Details
The RC 13.17 Annovi Reverberi solid shaft pump is a compact, high-performance pump designed for use in medium-duty commercial and industrial cleaning systems. Operating at 1450 RPM, it features a 24mm solid shaft, ideal for coupling directly to electric motors using either direct mounts or flexible joints.
Delivering 13 litres per minute at a maximum pressure of 170 Bar (2500 PSI), the RC13.17 requires approximately 5.5 HP to operate at full pressure. It utilises a 3-piston alternating volumetric design, powered by a crank-connecting rod mechanism, to provide efficient, reliable flow under continuous use.
The pump features a die-cast aluminium alloy body and cover for strength and corrosion resistance. A rear oil drain outlet is included for simple maintenance, with the side cover available with or without an integrated oil sight glass.
This is a versatile, serviceable pump popular in many OEM and replacement applications where compact size, long service life, and reliability are required.
Specifications
